Input voltage：Phase four-wire AC380V ± 15% Frequency 50Hz / 60Hz

Inverter output：Rated output voltage, three-phase four-wire AC380V ± 5a%, the frequency of 50 / 60Hz

Sine wave output：Pure sine wave

Drive power：≤19KW

Charging parameters：Rated charging voltage 55V, rated charging current of 0.7A

Working temperature：0 ℃ to 40 ℃, noise is less than 55db

Storage temperature：-20℃ to 50℃

Elevator running direction：Light load direction

Altitude：<2000M

Humidity：0-95% non-condensing

Battery pack：12V/9AH × 4

Size：680mm×300mm×180mm

Weight：30KG

Colour：Silver gray
